    Ignition Switch Replacement: How Do I Replace the Ignition Switch

    How do I get at it and how does the dash come off? Do you have the same problem? How do I replace the ignition switch? Ignition and start switch replacement. Disconnect the battery ground cable. Remove the steering column filler panel. Refer to Steering Column Filler Replacement. Remove the knee bolster bracket. Refer to Bracket Replacement - Knee Bolster. Remove the ignition switch bolts. Lower the ignition switch away from the instrument carrier. Insert the key into the ignition lock cylinder.

    The Passlock electrical connector cannot be removed until the lock cylinder is removed. Depress and hold the detent on the bottom of the ignition switch in order to release the ignition lock cylinder.

    2001 chevy impala ignition switch replacement

    Remove the ignition lock cylinder with the key. Disconnect the Passlock electrical connector. Disconnect the electrical connectors. Ignition switch lock cylinder that won't rotate or is seized. Perform the following procedure if the ignition switch lock cylinder is seized or won't rotate.

    Protect the immediate work area with suitable material such as clean shop towels or a clean fender cover. Remove portions of the broken spring from the hole using a small suitable tool. Grasp the ignition switch lock cylinder and remove it from the switch housing. Remove any plastic "flash" from the drilling operation, and using compressed air blow out the ignition switch assembly. Follow service manual procedures when cylinder cording is required.

    2001 chevy impala ignition switch replacement

    Installation Procedure If the lock cylinder would not rotate or was seized, perform the following procedure: Install the new ignition switch lock cylinder as required by rotating both the cylinder and the ignition switch to the ON position. Push the ignition switch lock cylinder into the ignition switch housing until fully seated. Connect the electrical connectors. Connect the Passlock electrical connector.

    Install the ignition lock cylinder into the ignition switch. If you turned the key slightly while removing the lock cylinder, you may have to align the white colored ignition switch rotor 1 with the lock cylinder 2. You can rotate the ignition switch rotor 1 with your finger. Position the ignition switch to the instrument carrier. Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure.

    Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.

    2001 chevy impala ignition switch replacement

    Install the ignition switch bolts. Tighten Tighten the bolts to 10 N m 89 lb in. Install the knee bolster bracket. Install the steering column filler panel. Connect the battery ground cable. Hello, I have a question regarding this install.

    I just replaced my ignition switch on my fathers Impala due to the popular pass-lock issue and the vehicle not starting. I purchased the ignition kit from GM, where a service tech told me I do not need to have the car re-keyed or programmed if I keep the stock tumbler and install it in the non-defective pass-lock.
